Description
Energy label
Technical Data Sheet
-
Frequency (Hz)50
-
Max absorbed current (A)1,4
-
Max absorbed power (W)165
-
Nominal diameter (mm)150
-
Voltage (V)220-240
-
Weight (Kg)33
-
Breakout sound power LWA [dB(A)]51,0
-
Breakout sound pressure at 3m at Max speed calculated in free field Lp [dB(A)]30,5
-
Max airflow (l/s)97,0
-
Max airflow (m³/h)350
-
Max pressure (mmH2O)58,0
-
Max pressure (Pa)568
-
Sound power at exhaust inlet LWA [dB(A)]37,8
-
Sound power at supply outlet LWA [dB(A)]37,2
-
Sound pressure at 3m at extraction at Max speed calculated in free field Lp [dB(A)]17,3
-
Sound pressure at 3m at supply at Max speed calculated in free field Lp [dB(A)]16,7
-
Ø (mm)150
-
Size A (mm)1183
-
Size B (mm)740
-
Size C (mm)288
-
Size D (mm)1287
-
Size E (mm)650
Interested?
If you are interested in this product, contact us or locate your nearest Vortice dealer.
Documentation
You can see all the documentation relating to this product: price list, information booklet and wiring diagram.
Accessories
Discover accessories related to the product
PANNELLO INSTALLATORE SKP10
Setting of machine parameters during initial installation procedures:
- speeds
- motors independently adjustable
- defrosting
- connection to any externa...
- speeds
- motors independently adjustable
- defrosting
- connection to any externa...
