VORT PROMETEO PLUS HR 400 M ITA/EXP

• Materials: fire-resistant expanded polypropylene; front panel made of filled thermoplastic resin
• Duct connection ports of nominal diameter 150 mm
• 2 x EC brushless motor with shafts turning in ball bearings, each coupled to a backward curved centrifugal impeller; 3 speeds, selectable independently at the moment of installation.
• Air flow settable between 50 m3/h and 380 m3/h
• Ultra high-efficiency counter-flow type heat exchanger fashioned from moulded plastic
• 100% bypass, manual control and operation
• Control unit supplied
• Automatically activated system designed to prevent icing of the heat exchanger.
• 2 x M5 filter (option of additional F7 filter on outlet duct)
• Compatible with operation piloted by Vortice ambient sensors: temperature (C Temp), relative humidity (C HCS) and smoke alarm (C Smoke). With operation interlocked to sensors, the local control functions are inhibited: the appliance continues to operate at minimum speed as long as the reference parameters monitored by the connected field sensors remain below the relative threshold values; when these values are exceeded, the appliance will switch to the maximum speed setting, which is then maintained until such time as normal ambient conditions are restored.
• Condensate drain hose;
• Pipette for connection of drain hoses
• Silencer of nominal diameter 150 mm and length 0.5 m, for installation downstream of the appliance on the
supply duct connecting with the rooms.
• 2 x metal bracket for suspended vertical mounting of the appliance.
• 4 x mount for horizontal installation.
• Energy performance certified by CASACLIMA (Italy), BRE (UK), CETIAT (France), EPBD (Belgium).
