Description

• Outer casing moulded from ABS thermoplastic resin.
• Alternating compressor, with protection device timed to delay restart by 3 minutes after each shutdown.
• Two operating speeds.
• Humidistat allowing preselection of residual moisture level in the room (HUM button: 50%, 60%, 70%, 80% or CONTINUOUS).
• Antifreeze thermostat designed to prevent icing internally of the appliance, thereby allowing operation even at low temperatures.
• Removable and washable dust filter serving to prevent the growth of bacteria inside the appliance and capture airborne dust particles.
• Set of indicator lights combined with a digital display, designed to show: operating status of the appliance, selected fan speed, and system lockout — accompanied by audible warning signal — triggered when water of condensation reaches the maximum limit in the collection tank (removable container holding 3.6 litres).
• Factory-prepared for connection to a tube of 6 mm diameter, so as to allow uninterrupted operation of the appliance without the need for periodic removal and emptying of the condensate collection tank.
• It contains fluorinated greenhouse gas.
• Hermetically sealed equipment.
Read full descriptionClose description
deumido_ambiente01

Technical Data Sheet

  • Compressor type
    Reciprocating
  • Frequency (Hz)
    50
  • Max absorbed current (A)
    1,44
  • Max absorbed power (W)
    250
  • Max ambient temperature for continuous operation (°C)
    32
  • Min continuous operation room temperature (°C)
    5
  • Number of phases (Ph)
    1
  • Number of speeds
    2
  • Refrigerant type
    R134a
  • Standard refrigerant charge (g)
    100
  • Tank capacity (l)
    3,6
  • Voltage (V)
    230-240
  • Weight (Kg)
    11
  • Dehumidification capacity (30 °C; 80% R.H.) (l/24h)
    10
  • Removed humidity (l/g) (at 30°C/80% R.H.)
    10
  • Sound pressure at 3 m - min speed Lp [dB (A)] 3m - min speed
    35
  • Sound pressure at 3m at Max speed Lp [dB (A)]
    37
  • Size A (mm)
    330
  • Size B (mm)
    522
  • Size C (mm)
    247
quota
Interested?
If you are interested in this product, contact us or locate your nearest Vortice dealer.
Documentation
You can see all the documentation relating to this product: price list, information booklet and wiring diagram.
