Description
Technical Data Sheet
-
Absorbed current at 400 V (A)20,8
-
Corrente Assorbita a 690 V (A)12,1
-
Frequency (Hz)50
-
IP55
-
Max absorbed power (W)11000
-
Motor classF
-
Operating temperature (°C)60
-
Voltage (V)400/690
-
Weight (Kg)180
-
Max airflow (m³/h)10510
-
RPM2940
-
Dimension B2 (mm)444
-
Dimension Q (mm)464,7
-
Dimension R (mm)530
-
Dimension U (mm)39,86
-
Dimension V (mm)43,9
-
Dimension Y (mm)65,9
-
Dimension Z (mm)8x45°
-
Dimensione A2 (mm)367,7
-
Dimensione HC (mm)570,6
-
Dimensione N1 (mm)284
-
Dimensione N2 (mm)334
-
Dimensione R1 (mm)362
-
Dimensione R2 (mm)500
-
Dimensione W (mm)410,6
-
DimensioneX (mm)160
-
Size B (mm)22,5
-
Size B1 (mm)325,4
-
Size C (mm)Ø 365
-
Size D (mm)Ø 485
-
Size D1 (mm)Ø 11,5
-
Size D2 (mm)Ø 20
-
Size E (mm)539,15
-
Size F (mm)526,6
-
Size G (mm)293
-
Size H (mm)48,5
-
Size I (mm)146,5
-
Size J (mm)520,3
-
Size K (mm)284,3
-
Size L (mm)385
-
Size M (mm)112
-
Size N (mm)364
-
Size O (mm)130
-
Size P (mm)130
-
Size S (mm)487
-
Size T (mm)563
