Description
Technical Data Sheet
-
Absorbed current at 400 V (A)14,1
-
Corrente Assorbita a 690 V (A)8,17
-
Frequency (Hz)50
-
IP55
-
Max absorbed power (W)7500
-
Motor classF
-
Operating temperature (°C)60
-
Voltage (V)400/690
-
Weight (Kg)103
-
Max airflow (m³/h)9510
-
RPM2910
-
Dimension B2 (mm)396,1
-
Dimension Q (mm)364,7
-
Dimension R (mm)480
-
Dimension U (mm)47,36
-
Dimension V (mm)57,8
-
Dimension Y (mm)45,71
-
Dimension Z (mm)8x45°
-
Dimensione A2 (mm)328,2
-
Dimensione HC (mm)510,6
-
Dimensione N1 (mm)252
-
Dimensione N2 (mm)302
-
Dimensione R1 (mm)322
-
Dimensione R2 (mm)450
-
Dimensione W (mm)378,6
-
DimensioneX (mm)132
-
Size B (mm)22,5
-
Size B1 (mm)294,3
-
Size C (mm)Ø 325
-
Size D (mm)Ø 438
-
Size D1 (mm)Ø 11,5
-
Size D2 (mm)Ø 20
-
Size E (mm)380,5
-
Size F (mm)406,5
-
Size G (mm)261
-
Size H (mm)38,5
-
Size I (mm)130,5
-
Size J (mm)464
-
Size K (mm)253
-
Size L (mm)270
-
Size M (mm)106
-
Size N (mm)332
-
Size O (mm)120
-
Size P (mm)120
-
Size S (mm)397
-
Size T (mm)473
