Description
Technical Data Sheet
-
Absorbed current at 400 V (A)10,6
-
Corrente Assorbita a 690 V (A)6,14
-
Frequency (Hz)50
-
IP55
-
Max absorbed power (W)5500
-
Motor classF
-
Operating temperature (°C)60
-
Voltage (V)400/690
-
Weight (Kg)85
-
Max airflow (m³/h)7810
-
RPM2910
-
Dimension B2 (mm)352,6
-
Dimension Q (mm)364,72
-
Dimension R (mm)435
-
Dimension U (mm)47,36
-
Dimension V (mm)20,2
-
Dimension Y (mm)45,71
-
Dimension Z (mm)8x45°
-
Dimensione A2 (mm)292,4
-
Dimensione HC (mm)460,6
-
Dimensione N1 (mm)224
-
Dimensione N2 (mm)274
-
Dimensione R1 (mm)282
-
Dimensione R2 (mm)405
-
Dimensione W (mm)329,6
-
DimensioneX (mm)132
-
Size B (mm)22,5
-
Size B1 (mm)266,2
-
Size C (mm)Ø 289
-
Size D (mm)Ø 394,5
-
Size D1 (mm)Ø 11,5
-
Size D2 (mm)Ø 20
-
Size E (mm)383,5
-
Size F (mm)406,52
-
Size G (mm)233
-
Size H (mm)35,5
-
Size I (mm)116,5
-
Size J (mm)412,8
-
Size K (mm)224.3
-
Size L (mm)270
-
Size M (mm)92
-
Size N (mm)304
-
Size O (mm)105
-
Size P (mm)105
-
Size S (mm)416
-
Size T (mm)492
