Description
Technical Data Sheet
-
Absorbed current at 230 V (A)10,3
-
Absorbed current at 400 V (A)5,92
-
Frequency (Hz)50
-
IP55
-
Max absorbed power (W)3000
-
Motor classF
-
Operating temperature (°C)60
-
Voltage (V)230/400
-
Weight (Kg)55
-
Max airflow (m³/h)5310
-
RPM2880
-
Dimension B2 (mm)314,1
-
Dimension Q (mm)272,95
-
Dimension R (mm)395
-
Dimension U (mm)36,47
-
Dimension V (mm)26,3
-
Dimension Y (mm)46,47
-
Dimension Z (mm)8x45°
-
Dimensione A2 (mm)260,7
-
Dimensione HC (mm)415,6
-
Dimensione N1 (mm)198
-
Dimensione N2 (mm)248
-
Dimensione R1 (mm)251
-
Dimensione R2 (mm)365
-
Dimensione W (mm)315,6
-
DimensioneX (mm)100
-
Size B (mm)22,5
-
Size B1 (mm)241,3
-
Size C (mm)Ø 257,12
-
Size D (mm)Ø 354,5
-
Size D1 (mm)Ø 11,5
-
Size D2 (mm)Ø 20
-
Size E (mm)364,6
-
Size F (mm)316,51
-
Size G (mm)207
-
Size H (mm)35,5
-
Size I (mm)103,5
-
Size J (mm)367,5
-
Size K (mm)198,5
-
Size L (mm)200
-
Size M (mm)79
-
Size N (mm)278
-
Size O (mm)90
-
Size P (mm)95
-
Size S (mm)344
-
Size T (mm)430
